| Product Name: | R300 Desktop Retransfer Dual-sided Card Printer |
| Print Method: | Dye Sublimation retransfer printing |
| Print Resolution: | 300dpi × 300dpi |
| LCM Display: | 3.5 inch color touch-screen |
| Memory: | 256MB |
| Print Speed: | Monochrome printing:12-16s per card(single-sided), 30-34s per card(dual-sided),using ribbon saving technology |
| Full-color YMCK Printing：20s per card(single-sided),38s per card(dual-sided) | |
| Card Size: | ISO CR80(53.98mm×85.60mm) |
| Card Thickness: | 0.3-1.05mm (hopper adjustment required) |
| Card Material: | PVC, composite PVC, ABS, PET, PC and other materials |
| Input Hopper Capacity: | 200pcs(0.76mm) |
| Output Hopper Capacity: | 200pcs(0.76mm) |
| Defective card slot capacity: | 25pcs(0.76mm) |
| Body Size: | 568mm × 272mm × 398mm |
| N.W: | 20.3 Kg |
| Software: | Driver: Support 32-bit and 64-bit Windows® XP, 7, 8, 10, Windows® Server 2003/2008/2012/2016/2019; 32-bit and 64-bit Linux, Android. Support Chinese operating systems,such as the NeoKylin, Kylin and UnionTech UOS. |
| Card design software: iCARDE card design software Supports 32-bit and 64-bit Windows® XP, 7, 8, 10, Windows® Server 2003/2008/2012/2016/2019 | |
| Interfaces: | Standard USB2.0&Ethernet,WIFI(optional) |
| Power: | 100-240VAC，50/60Hz，4A |
| Operation Condition: | 1.Regular running temp.:15℃-30℃(59-86℉),20%-65%RH non-condensing. |
| 2.Lowest/Highest running temp.:0℃(32℉)/40℃(104℉),20%-65%RH non-condensing. | |
| Consumables: | 1. Monochrome ribbon: 100m×60mm; |
| 2. YMCK ribbon full panel : 500 / 1000 prints/roll; | |
| 3. YMCKK ribbon full panel: 500 prints/roll; | |
| 4. YMCKI ribbon full panel: 500 prints/roll; | |
| 5. YMCKHs ribbon full panel: 500 prints/roll; | |
| 6. Security YMCFK ribbon: 500 print/roll; | |
| 7. Transparent retransfer film: 500 / 1000 prints/roll. | |
| Certificates: | CCC, FCC, CE, ROHS, BIS, UKCA |
| Optional Encoding Module | 1. Dual interface chip card reading and writing module: Support (ISO 7816, T=1 & T=0), 4 SAM slots (same as SIM card size complied with GSM 11.11), Support contactless CPU card (ISO14443 TYPE A/B),PC/SC |
| 2.Contactless ID card encoding module: Support read and write 125KHz RFID smart card (ATA5567, ATA5577, EM4469, EM4305, hitag-s and other common ID chip cards | |
| 3.UHF Chip card encoding module: Support EPC C1 GEN2/ ISO 18000 -6C Air interface protocol standard | |
| 4.Magnetic stripe card encoding module: Support ISO7811 Hi-co/Low-co,support 1/2/3 tracks encoding |
